Detailed explanation of Incoloy 800H pipe
Incoloy 800H seamless pipes are made from the nickel-iron-chromium alloy Incoloy 800H without any welds in the manufacturing process. The seamless manufacturing process involves extruding a solid billet into a hollow tube. Incoloy 800H seamless pipes have high strength, excellent corrosion resistance and good structural integrity for use in high temperature and corrosive environments. They are commonly used in industries such as chemical processing, power generation and petrochemical.
Gnee Steel
What is 800H Alloy Tube Material?
800H Alloy Tube is an austenitic heat resistant nickel iron chromium solid solution alloy with controlled levels of carbon, aluminum, titanium, silicon and manganese and (aluminum + titanium).
Chemical Composition of Incoloy 800H Pipes
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
Mechanical Properties of Incoloy 800H Pipes
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800H | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
Incoloy 800H Pipes Application Industries
Aerospace Industry
Chemical Industry
Energy Industry
Food Processing Industry
Oil and Gas Industry
Petrochemical Industry
Pulp & Paper Indusry
Pharmaceuticals Industry
Power Plant Industry
Incoloy 800 Pipe Pressure Rating
| Pipe O.D. (in.) |
Wall Thickness of Pipe (inches) | |||||||
| .028 | .035 | .049 | .065 | .083 | .095 | .109 | .120 | |
| Working Pressure (psig) | ||||||||
| 1/8 | 7900 | 10100 | ||||||
| 1/4 | 3700 | 4800 | 7000 | 9500 | ||||
| 5/16 | 3700 | 5400 | 7300 | |||||
| 3/8 | 3100 | 4400 | 6100 | |||||
| 1/2 | 2300 | 3200 | 4400 | |||||
| 3/4 | 2200 | 3000 | 4000 | 4600 | ||||
| 1 | 2200 | 2900 | 3400 | 3900 | 4300 | |||
UNS N08800 Pipe Schedule Chart
|
1/8" IPS(.405"O. D.) |
3 1/2" IPS( 4.000"O. D.) |
|
SCH 40, 80 |
SCH 10, 40, 80, 160, XXH |
|
1/4" IPS(.540"O. D.) |
4" IPS(4.500"O. D.) |
|
SCH 10, 40, 80 |
SCH 10, 40, 80, 160, XXH |
|
3/8" IPS(.675"O. D.) |
5" IPS( 5.563"O. D.) |
|
SCH 10, 40, 80 |
SCH 10, 40, 80, 160, XXH |
|
1/2" IPS(.840"O. D.) |
6" IPS(6.625"O. D.) |
|
SCH 5, 10, 40, 80, 160, XXH |
SCH 5, 10, 40, 80, 120, 160, XXH |
|
3/4" IPS(1.050"O. D.) |
8 " IPS(8.625"O. D.) |
|
SCH 10, 40, 80, 160, XXH |
SCH 5, 10, 40, 80, 120, 160, XXH |
|
1" IPS:(1.315′O. D.) |
10" IPS(10.750"O. D.) |
|
SCH 5, 10, 40, 80, 160, XXH |
SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
|
1-1/4" IPS(1.660"O. D.) |
12" IPS(12.750"O. D.) |
|
SCH 10, 40, 80, 160, XXH |
SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
|
1-1/2" IPS(1.900"O. D.) |
14" IPS(14.000"O. D.) |
|
SCH 10, 40, 80, 160, XXH |
SCH10 (.188), SCH40 (.375) |
|
2" IPS(2.375"O. D.) |
16" IPS(16.000"O. D.) |
|
SCH 10, 40, 80, 160, XXH |
SCH10(.188), SCH40(.375) |
|
2 1/2" IPS(2.875"O. D.) |
18" IPS (18.000"O. D.) |
|
SCH 10, 40, 80, 160, XXH |
SCH-40 (.375) |
|
3" IPS( 3.500"O. D.) |
|
|
SCH 5, 10, 40, 80, 160, XXH |
Gnee Steel is a supplier of Incoloy 800H pipe, with products covering pipes: seamless pipes: size: 4 - 219 mm; thickness: 0.5 - 20 mm; welded pipes: size: 5.0 - 1219.2 mm; thickness: 0.5 - 20 mm, plates: plate thickness 0.1 to 100 mm; plate width 10-2500 mm, strips, alloy round bar size: diameter 3-800 mm;, flat bar size: thickness 2-100 mm; width: 10-500 mm, hexagonal bar size: 2-100 mm;, wire and extruded profiles. We work with steel mills to provide customers with 625 alloy, and its products meet or exceed many leading industry standards, including ASTM, ASME, SAE, AMS, ISO, DIN, EN and BS standards.
