Detailed information on Nickel 600 and 625 alloy tubing
Nickel alloy 600 (Inconel 600) and 625 alloy (Inconel 625) tubes are high-performance nickel-chromium alloy tubes, primarily differing in composition and corrosion resistance/strength. 600 alloy tubes offer excellent high-temperature strength and oxidation resistance (up to 2000°F), making them ideal for heat exchangers; while 625 alloy square tubes, with the addition of molybdenum, exhibit superior strength, creep resistance, and corrosion resistance in marine/chemical applications, with a maximum operating temperature of 1800°F. Due to the addition of molybdenum and controlled manganese content, 625 alloy seamless tubes possess better creep strength, fatigue strength, and tensile strength, making them more suitable than the more basic, high-temperature-focused 600 alloy round tubes for applications requiring extreme corrosion resistance and high strength.
What is Nickel Alloy 600?
Nickel Alloy 600 bars, rods, and wires are a nickel-chromium alloy that exhibits excellent oxidation resistance at high temperatures. Due to its corrosion resistance to various acids and alkalis, it is also frequently used as a corrosion-resistant alloy.
What is Nickel Alloy 600?
Inconel 600 alloy tubing is a nickel-chromium alloy. It has very good oxidation resistance at high temperatures. In addition, it exhibits excellent corrosion resistance to carburizing and chlorine-containing atmospheres. It is a non-magnetic alloy and possesses very good mechanical properties.
What is Inconel 625 tubing?
Inconel 625 is a nickel-based superalloy tubing. It possesses very good strength characteristics and can withstand extremely high temperatures. Furthermore, it has good oxidation and corrosion resistance. It can also withstand a wide range of temperatures and significant stress.
600/625 Inconel Pipes Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
Chemical Composition of Alloy Seamless 600/625 Pipes and Tubes
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
|---|---|---|---|---|---|---|---|---|
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | - | 5.0 max | 58.0 min | 20.0 - 23.0 |
Mechanical Properties of Nickel Alloy 600/625 Pipes and Tubes
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
Corrosion Resistance
Nickel Alloy 600 Seamless Tubes:
Excellent oxidation and corrosion resistance at high temperatures.
Suitable for dry gas, chloride, and oxidizing environments.
Limited resistance to pitting and crevice corrosion compared to Alloy 625.
Nickel Alloy 625 Alloy Tubes:
Possesses superior corrosion resistance, especially in seawater, chloride-containing environments, and acidic media.
Due to the presence of molybdenum and niobium, its resistance to pitting, crevice corrosion, and stress corrosion cracking is significantly enhanced.
Temperature resistance of Nickel 600 and 625
| Temperature Range | Nickel Alloy 600 Pipe | Nickel Alloy 625 Tube |
|---|---|---|
| Continuous Service | Up to 1100°C (2000°F) | Up to 980°C (1796°F) |
| Cryogenic Temperatures | Good | Excellent |
