N08020/ASTM B 463 Superalloy Nickel Strip For Petroleum Processing Equipment Incoloy 20 Alloy Coil
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Alloy 20 (UNS N08020, W. Nr 2.4660) is a nickel-iron-chromium alloy which has the addition of copper and molybdenum. With the additions of niobium Alloy 020 is stabilized against sensitization and resultant intergranular corrosion. Alloy 020 has excellent resistance to general corrosion, pitting and crevice corrosion and is commonly used for chemical, pharmaceutical and food processing, tanks, piping, heat exchangers, pumps, Kevlar production and much more.
Application
▪ Production of plastics and synthetic fibers
▪ Chemical and petroleum processing equipment
▪ Mixing tanks
▪ Heat exchangers
▪ Process piping
Chemical Composition
| Weight % | Ni | Cr | Cu | Mo | Fe | C | Nb+Ta | Mn | P | S | Si |
| Alloy 20 | 32.0 - 38.0 | 19 - 21 | 3 - 4 | 2 - 3 | bal | 0.07 max | 8 x C-1 | 2 max | 0.045 max | 0.035 max | 1.0 max |
Incoloy 20 Mechanical Properties
| Material | Yield Strength (0.2% Offset) | Tensile Strength | Elongation % | ||
| psi | MPA | psi | MPA | Elongation (%) | |
| Alloy 20 | 45,000 | 300 | 90,000 | 620 | 40 |
Our Company
