Name: Monel 400 N04400 2.4360 Alloy Sheet - China Monel 400 N04400 2.4360 Alloy Sheet Suppliers - Super Alloy
Brand: GNEE
SKU: 238633854

The Monel 400 material is a copper-nickel alloy that comes with some excellent mechanical properties. The Monel 400 Plate has high ductility, and they are quite durable too.

Send Inquiry

Chat Now

As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.

Send E-mail: ss@gneesteel.com
Tel: +8615824687445

Product Introduction

Monel Alloy 400 is a nickel-copper (about 67% Ni – 23% Cu) solid solution strengthened alloy. The alloy is characterized by moderate strength, good weldability, good general corrosion resistance and toughness. It is useful at temperatures up to 1000°F (538°C). Alloy 400 has excellent resistance to rapidly flowing brackish or seawater where cavitation and erosion resistance is necessary. It is particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated. Alloy 400 is slightly magnetic at room temperature.

ASTM Specifications

Pipe Smls	Pipe Welded	Tube Smls	Sheet / Plate	Bar	Forging	Fitting
B165	B725	B163	B127	B164	B564	B366

Chemical Composition

Trade Name

ASTM/AISI

Alloy type

UNS

%Cu

%Fe

%Mn

%Si

%Ni

Monel 400

B 127, B 164

N04400

28–34

2.5 max

2.0 max

0.5 max

63 min

Mechanical Properties Minimum Room Temperature Tensile Data

Product Form	Condition	Tensile (ksi)	.2% Yield (ksi)	Elongation (%)	Hardness (HRB)
Rod & Bar	Annealed	75-90	25-50	60-35	60-80
Rod & Bar	Cold-Drawn Stress Relieved	84-120	55-100	40-22	85-20 HRC
Plate	Annealed	70-85	28-50	50-35	60-76
Sheet	Annealed	70-85	30-45	45-35	65-80
Tube & Pipe Seamless	Annealed	70-85	25-45	50-35	75 max*

monel 400 sheet

Applications Of Monel N04400 Alloy Sheet

Marine engineering
Chemical and hydrocarbon processing equipment
Gasoline and freshwater tanks
Crude petroleum stills
De-aerating heaters
Boiler feed water heaters and other heat exchangers
Valves, pumps, shafts, fittings, and fasteners
Industrial heat exchangers
Chlorinated solvents
Crude oil distillation towers

Characteristics of Monel Alloy 400 Sheet

Resistant to seawater and steam at high temperatures
Excellent resistance to rapidly flowing brackish water or seawater
Excellent resistance to stress corrosion cracking in most freshwaters
Particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated
Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations, but is seldom the material of choice for these acids
Excellent resistance to neutral and alkaline salt
Resistance to chloride induced stress corrosion cracking
Good mechanical properties from sub-zero temperatures up to 1020° F
High resistance to alkalis
