Inconel 601 Plate
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Uns N06601 Alloy Plate description
GNEE Inconel 601 Sheet
Gnee Steel supplies Inconel 601 sheet (UNS N06601) – a high-quality nickel-based superalloy renowned for its excellent corrosion resistance, high-temperature strength, and superior machinability. Our Inconel 601 sheet fully complies with ASTM B168 standards, ensuring consistent stability, durability, and superior performance in a wide range of industrial applications.
Gnee Steel offers a wide range of high-quality Inconel 601 Plate in various sizes, and provides customization services and worldwide shipping to meet your specific project needs.
Contact us now to get an export quote for Inconel 601 Plate
Key Advantages of Gnee Steel Inconel 601 Sheet Metal:
Superior Oxidation Resistance: The addition of aluminum forms a protective oxide layer, effectively preventing peeling during cyclic heating.
Corrosion Resistance: Excellent resistance to water corrosion and effective resistance to "sponge-in" corrosion in the furnace environment.
Ease of Machining: Our sheet metal possesses excellent mechanical strength and can be easily welded and machined using standard industrial techniques.
Dimensional Accuracy: We use advanced cold rolling technology to produce 601 alloy sheet metal with high dimensional accuracy.
Specification of Nickel 601 plate
| Thickness of Inconel Alloy 601 Plate | 0.3 to 1200 mm or as required |
|---|---|
| Process for manufacturing of ASTM B168 Inconel 601 Plate | Hot Rolled/ Cold Rolled |
| Length of Inconel 601 Plate | 0-12mm or as required |
| Inconel UNS N06601 Plate Width | 0-2500mm or as required |
| Available surfaces of Alloy 601 Plate | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled Inconel 601 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
Inconel 601 Plate Specification
Inconel UNS N06601 Mechanical Characteristics
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Nickel 601 plate Chemical Formula
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 0.015max | 1.00 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
Equivalent grades of Inconel 601 plate
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
Inconel 601 Sheet Technical Data Sheet
Inconel 601 Sheets Plate Thickness Tolerance Chart
| Gauge | LB/Sq. Ft. | LB/Sq In. | Plate Gauge Tolerance | ||
|---|---|---|---|---|---|
| 72″ Wide | 96″ Wide | ||||
| 3/16 | 0.1875 | 8.579 | 0.05958 | +.045″ -.010″ | +.050″ -.010″ |
| 7/32 | 0.2187 | 9.870 | 0.06854 | ||
| 1/4 | 0.2500 | 11.162 | 0.07750 | ||
| 5/16 | 0.3125 | 13.746 | 0.09546 | ||
| 3/8 | 0.3750 | 16.496 | 0.11456 | +.055″ -.010″ | +.060″ -.010″ |
| 7/16 | 0.4375 | 19.080 | 0.13250 | ||
| 1/2 | 0.5000 | 21.633 | 0.15044 | ||
| 9/16 | 0.5625 | 24.247 | 0.16838 | ||
| 5/8 | 0.6250 | 26.831 | 0.18633 | ||
| 11/16 | 0.6875 | 29.415 | 0.20427 | ||
| 3/4 | 0.7500 | 32.123 | 0.22308 | +.060″ -.010″ | +.065″ -.010″ |
| 13/16 | 0.8125 | 34.707 | 0.24102 | ||
| 7/8 | 0.8750 | 37.291 | 0.25897 | ||
| 15/16 | 0.9375 | 39.875 | 0.27691 | ||
| 1 | 1.0000 | 42.665 | 0.29628 | +.070″ -.010″ | +.075 -.010″ |
| 1-1/8 | 1.1250 | 47.833 | 0.33217 | ||
| 1-1/4 | 1.2500 | 53.001 | 0.36806 | ||
| 1-3/8 | 1.3750 | 58.169 | 0.40395 | ||
| 1-1/2 | 1.5000 | 63.337 | 0.43984 | ||
| 1-3/4 | 1.7500 | 73.672 | 0.51161 | ||
| 2 | 2.0000 | 84.008 | 0.58339 | +.125″ -.010″ | +.150″ -.010″ |
| 2-1/8 | 2.1250 | 89.610 | 0.62229 | ||
| 2-1/4 | 2.2500 | 94.777 | 0.65817 | ||
| 2-1/2 | 2.5000 | 105.113 | 0.72995 | ||
| 2-3/4 | 2.7500 | 115.449 | 0.80173 | ||
| 3 | 3.0000 | 126.301 | 0.87709 | +.150″ -.010″ | +.160″ -.010″ |
| 3-1/2 | 3.5000 | 146.972 | 1.02064 | ||
| 4 | 4.0000 | 168.264 | 1.16850 | +.180″ -.010″ | +.200″ -.010 |
Inconel 601 Sheets Plate Thickness Chart In Mm
| Plate Thickness (mm) |
Plate Weight (kg/m2) |
|---|---|
| 2.0 | 15.7 |
| 1.6 | 12.6 |
| 3 | 23.6 |
| 2.5 | 19.6 |
| 3.2 | 25.1 |
| 5 | 39.3 |
| 4 | 31.4 |
| 6 | 47.1 |
| 10 | 78.5 |
| 8 | 62.8 |
| 12.5 | 98.1 |
| 20 | 157 |
| 15 | 118 |
| 22.5 | 177 |
| 30 | 236 |
| 25 | 196 |
| 32 | 251 |
| 40 | 314 |
| 35 | 275 |
| 45 | 353 |
| 55 | 432 |
| 50 | 393 |
| 60 | 471 |
| 70 | 550 |
| 65 | 510 |
| 75 | 589 |
| 250 | 1963 |
| 90 | 707 |
| 80 | 628 |
| 150 | 1178 |
| 100 | 785 |
| 120 | 942 |
| 110 | 864 |
| 130 | 1051 |
| 180 | 1413 |
| 160 | 1256 |
| 200 | 1570 |
Inconel 601 Sheets and Plates Thickness Tolerance
Plate Width (w), in. [mm] |
||||
|---|---|---|---|---|
| Specified Thickness (t), in. [mm] | w > 144 [ 3658] | 84 [2134] < w ≤ 120 [3048] | w ≤ 84 [2134] | 120 [3048] < w ≤ 144 [3658] |
|
Tolerance Over Specified Thickness, *** in. [mm] |
||||
| 3/4 [19.05] ≤ t < 1 [25.04] | 0.100 [2.54] | 0.065 [1.65] | 0.060 [1.52] | 0.085 [2.16] |
| 8 [203.2] ≤ t < 10 [254.0] | 0.550 [14.0] | 0.335 [8.50] | 0.315 [8.00] | 0.435 [11.0] |
| 2 [ 50.80] ≤ t < 3 [76.20] | 0.200 [5.08] | 0.150[3.80] | 0.125 [3.20] | 0.175 [4.45] |
| 3/16 [4.76] ≤ t < 3/8 [9.52] | -- | 0.050 [1.27] | 0.045 [1.14] | 0.085 [2.16] |
| t < 3/16 [4.76] | -- | 0.070 [1.78] | 0.055 [1.35] | -- |
| 1 [25.40] ≤ t < 2 [50.80] | 0.115 [2.92] | 0.075 [1.90] | 0.070 [1.78] | 0.095[2.41] |
| 4 [101.6] ≤ t < 6 [152.4] | 0.355 [9.02] | 0.200 [5.08] | 0.180 [4.75] | 0.335 [8.50] |
| 3 [76.20] ≤ t < 4 [101.6] | 0.225 [5.72] | 0.160 [4.06] | 0.150 [3.81] | 0.200 [5.08] |
| 6 [152.4] ≤ t < 8 [203.2] | 0.435 [11.0] | 0.255 [6.48] | 0.235 [6.00] | 0.355 [9.02] |
Inconel 601 Sheets & Plate Standard Size Chart
| 2000MM X 1000MM X 3MM | 2000MM X 1000MM X 6MM |
| 2500MM X 1250MM X 4MM | 2500MM X 1250MM X 8MM |
| 3000MM X 1500MM X 3MM | 3000MM X 1500MM X 6MM |
| 3000MM X 1500MM X 4MM | 3000MM X 1500MM X 8MM |
| 2000MM X 1000MM X 5MM | 2500MM X 1250MM X 10MM |
| 2500MM X 1250MM X 3MM | 2500MM X 1250MM X 6MM |
| 4000MM X 2000MM X 3MM | 4000MM X 2000MM X 6MM |
| 2500MM X 1250MM X 5MM | 3000MM X 1500MM X 10MM |
| 2000MM X 1000MM X 4MM | 2000MM X 1000MM X 8MM |
| 4000MM X 2000MM X 4MM | 2000MM X 2000MM X 10MM |
| 3000MM X 1500MM X 5MM |
Gnee Steel offers the full range of Inconel 601 products.
You may be looking for Inconel 601 sheets, but most industrial projects require a comprehensive material solution. We offer a one-stop shop for the Inconel 601 product range:
Uns N06601 Alloy Plate Price List
| Price Rang by country | Sheet Price (per kg) |
Plate Price (per kg) |
Coil Price (per kg) |
|---|---|---|---|
| Inconel 601 Stainless Steel Price in India (₹) | 280 - 300 | 300 - 350 | 260 - 280 |
| Inconel 601 Price in Malaysia (RM) | 15.51 - 16.62 | 16.62 - 19.39 | 14.41 - 15.51 |
| Inconel 601 Price in Singapore (S$) | 5.02 - 5.38 | 5.38 - 6.28 | 4.66 - 5.02 |
| Inconel 601 Price in UAE (Dirham) | 13.51 - 14.47 | 14.47 - 16.88 | 12.54 - 13.51 |
| Inconel 601 Stainless Steel Price in UK ( £) | 2.77 - 2.97 | 2.97 - 3.46 | 2.57 - 2.77 |
| Inconel 601 Stainless Steel Price in Europe (€) | 3.25 - 3.49 | 3.49 - 4.07 | 3.02 - 3.25 |
| Inconel 601 Price in USA ($) | 3.68 - 3.94 | 3.94 - 4.60 | 3.42 - 3.68 |
Inconel 601 Sheet Shipping Time As Per Location
| Price Variations 5 % extra | |
|---|---|
| Export to | Shipping Time in Days |
| Malaysia | 10 |
| Italy | 30 |
| Philippines | 14 |
| Oman | 5 |
| Kuwait | 10 |
| South Africa | 25-30 |
| UAE | 5 days |
| USA | 40-60 |
| Bahrain | 9 |
| Saudi Arabia | 7 |
| Singapore | 8 |
| Qatar | 7 |
| France | 30 |
| Uk | 30 |
| Indonesia | 9 |
Products and services offered by Gnee Steel
Applications of Inconel 601 Plate
Aerospace: Jet engine components, gas turbine parts, rocket engines, and fasteners.
Oil and Gas: Downhole drill pipes, wellhead components, valves, and pump assemblies.
Chemical Industry: High-temperature reactors and pipelines.
Marine: Submarine components and high-strength shafts.
Nuclear Energy: Reactor core and control rod components.
Packaging method for Alloy 601 Sheet
Gnee Steel uses the safest and most effective packaging methods for all types of cargo transportation. Our packaging methods include:
Wooden crates
Wooden pallets
Shrink wrap packaging
Cardboard boxes
Wooden crates (slatted)
Inconel 601 Plate material certificate
Inconel 601 Plate material certificate
About Gnee Steel
Request the latest Inconel 601 Plate price list. Please call +8615824687445 or email ss@gneesteel.com for information on available stock and the latest price list for Nickel 600 Plate.
Please contact us to get a quick quote for the inconel 601 Sheet you need
We supply these Inconel 601 Plate according to DIN, ISO, JIS, or ANSI/ASME standards.
"We provide DDP/CIF shipping services to Germany and Italy."
FAQ
Q：What are the applications of Inconel 601?
A：In industrial furnaces, this alloy is used to manufacture radiant tubes, muffle furnaces, rotary furnaces, flame shields, annealed coil tubes, braided conveyor belts, chain curtains, burner nozzles, and resistance heating elements.
Q：What is Inconel sheet metal?
A：Inconel (/ˈɪnkənəl/ IN-co-nel) is a high-temperature alloy primarily composed of nickel, chromium, and iron, commonly used in components subjected to extreme environments of high temperature, high pressure, or mechanical loads. Inconel alloys exhibit excellent oxidation resistance and corrosion resistance.
Q：What is Inconel 601?
A：Inconel 601 is a nickel-chromium alloy with extremely strong oxidation resistance below 2200°F (1200°C). The 601 alloy forms a tightly adhering oxide layer that prevents peeling even under severe thermal cycling. This alloy has good high-temperature strength and maintains good ductility even after long-term use.
Q：What is the difference between Inconel 601 and 602?
A：Inconel 601 offers excellent oxidation resistance and tensile strength, making it suitable for high-temperature applications. In contrast, Inconel 602 exhibits superior creep resistance and sulfidation resistance, making it ideal for reducing environments.
Q：What is Inconel 601 material?
A：Inconel 601 alloy is a nickel-based alloy with a high chromium content (approximately 25 wt%) and added aluminum, designed to resist the effects of high-temperature oxidizing atmospheres during metal and material heat treatment.
