Nickel 201 UNS N02201 ASTM B161 Low-carbon Nickel Alloy Seamless Pipe
ASTM B163 200 / 201 Nickel Seamless Tubes Equivalent Grades Nickel UNS N02200 / N02201 Seamless Tubes Chemical Composition Nickel Alloy WERKSTOFF NR. 2.4066 / 2.4068 Seamless Tube Mechanical Properties SME SB 163 UNS N02201Seamless Tube Outside Diameter & Wall Thickness Tolerance Our Company
Send Inquiry
Chat Now
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Product Introduction
ASTM B163 200 / 201 Nickel Seamless Tubes Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 200 | N02200 | 2.4066 | N-100M | Ni 99.2 | NW 2200 | NA 11 | НП-2 |
| Nickel 201 | N02201 | 2.4068 | - | LC-Ni 99 | NW 2201 | NA 11 | НП-2 |
Nickel UNS N02200 / N02201 Seamless Tubes Chemical Composition
| Grade | Ni(min) | Fe(max) | Cu(max) | C(max) | Mn(max) | S(max) | Si(max) | Mg(max) | Ti(max) |
| Nickel Alloy 200 | 99.0 | 0.40 | 0.25 | 0.15 | 0.35 | 0.01 | 0.35 | ||
| Nickel Alloy 201 | 99.0 | 0.40 | 0.25 | 0.02 | 0.35 | 0.01 | 0.35 | ||
| DIN 17744 17750 17752 17753 2.4066 | 99.2 | 0.40 | 0.25 | 0.10 | 0.35 | 0.005 | 0.25 | 0.15 | 0.10 |
Nickel Alloy WERKSTOFF NR. 2.4066 / 2.4068 Seamless Tube Mechanical Properties
| Grade | Density | Yield Strength (0.2%Offset) | Tensile Strength | Elongation | Melting Point |
| Nickel Alloy 200 / 201 | 8.9 g/cm3 | Psi - 21500 , MPa - 148 | Psi - 67000 , MPa - 462 | 45% | 1446 °C (2635 °F) |
SME SB 163 UNS N02201Seamless Tube Outside Diameter & Wall Thickness Tolerance
| Material | Nominal O.D., in. (mm) | Permissible Variations [Note(1)] | |||||
| O.D., in. (mm) | Wall Thk., % | ||||||
| Avg Wall | Min. Wall | ||||||
| + | - | + | - | + | - | ||
| UNS N02200, UNS N02201, and UNS N04400 |
1/2 to 5/8 (12.7 to 15.9),excl | 0.005(0.13) | 0 | 12.5 | 12.5 | 25 | 0 |
| 8/5 to 1 1/2(15.9 to 38.1), incl | 0.005(0.13) | 0.005(0.13) | 10 | 10 | 20 | 0 | |
| Over 1 1/2 to 3(38.1 to 76.2), incl | 0.010(0.25) | 0.010(0.25) | 10 | 10 | 22 | 0 | |
| UNS N06600, UNS N066090, UNS N06045, UNS N06025, UNS N08800, UNS N08810, UNS N08811, UNS N08801, and UNS N08825 |
1/2 to 5/8 (12.7 to 15.9), excl | 0.005(0.13) | 0.005(0.13) | 12.5 | 12.5 | 25 | 0 |
| 8/5 to 1 1/2 (15.9 to 38.1), incl | 0.0075(0.19) | 0.0075(0.19) | 10 | 10 | 20 | 0 | |
| Over 1 1/2 to 3 (38.1 to 76.2), incl | 0.010(0.25) | 0.010(0.25) | 10 | 10 | 22 | 0 | |
Our Company
