ASTM B516 UNS N06601 ERW Tubing
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
ASTM B516 UNS N06601 Alloy Welded Pipe is a nickel-based alloy, welded pipe made of N06601 alloy material, also known as Incone1601. It has excellent high temperature resistance and oxidation resistance, and is widely used in the manufacture of high temperature equipment, such as furnaces, heat treatment equipment, chemical reactors and furnaces, etc.
GNEE provides ASTM B516 welded pipes including: Inconel 601 Alloy ERW Pipe, Inconel 601 Alloy EFW Pipe, ASME SB 516 condenser tubes,ASME SB 516 Heat Exchanger Tube ,which can be customized according to the customer's actual project and provide the required test certificates.
Products Data
ASME SB 516 N06600 Welded Tube
OD: 6.35 to 114.3 mm
Thickness:0.8 to 12.7 mm
Length: up to 26 Meters
Chemical Composition of ASTM B516 UNS N06601 ERW Tubes
| Elements | Composition Limits, % |
|---|---|
| Inconel 601 | |
| Nickel | 58.0 to 63.0 |
| Chromium | 21.0 to 25.0 |
| Iron | Remainder |
| Manganese | 1.5 max |
| Aluminum | 1.0 to 1.7 |
| Carbon | 0.10 max |
| Copper | 1.0 max |
| Silicon | 0.5 max |
| Sulfur | 0.015 max |
Mechanical Properties ASTM B516 material UNS N06601 pipes
| Grade | Tensile Strength min, psi (MPa) | Elongation in 2 inches or 50mm or 4D min, % | Yield Strength (0.2% offset), min, psi (MPa) |
|---|---|---|---|
| Inconel 601 | 80 000 (550) | 30 | 30 000 (205) |
Products Display
ASTM B 516 N06601 boiler tube
Why Choose GNEE
GNEE has vacuum induction melting, electroslag remelting, forging, heat treatment and machining production lines, and can provide bars, plates, flanges and forgings.
We are happy to offer the best prices for both small and large quantities and can usually deliver DIN 2.4851 pipes to anywhere in the world in the shortest possible time. please feel free to contact us. ss@gneesteel.com
GNEE CUSTOMER VISIT
GNEE FACTORY ENVIRONMENT
GNEE PACKAGING AND SHIPPING
PRODUCTS TESTING
FAQ
Q: Do you have quality control?
A: Yes, we have gained BV, SGS authentication.
Q: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 25-45 days if the goods are not in stock, it is according to quantity.
